Laser Precision, Unmatched Visuals

The W5800 features a groundbreaking laser array light source, presenting a breathtaking 4K image with an impressive brightness of 2,600 lumens for vivid color and clarity.

Colours as Directors Envisioned

Faithfully reproduce the image the way the artist intended. BenQ W5800 Home Cinema Projectors with CinematicColor super-wide 100% DCI-P3 and 100% Rec.709 color space deliver precise colors to perfectly preserve what the directors envisioned.

Exclusive Colour Temperature Tuning

BenQ high-end cinema projectors provide advanced color temperature tuning with leading 11 levels of white balance controls between high to low brightness, enabling content fanatics to adjust the most accurate colors in mid-tone colors.

Filmmaker Mode

Most movies are shot at 24 frames per second (fps). In order to display movies exactly as the director intended, the W5800 supports 24P playback that accepts high-definition sources at 24 fps without judder in HDR mode to preserve the purity of the original image.

4K Clarity Through All-Glass Lens

Utilizing an all-glass lens system featuring 14-element 7-group coated with low dispersion materials, the W5800 has superior transparency to greatly reduce color difference, fully displaying 4K image clarity.

HDR Tone Mapping

BenQ exclusive HDR-PRO technology heightens the 4K HDR viewing experience with two-step enhanced tone mapping, reproducing more balance between details in bright and dark scenes.

Comprehensive Image Optimization

BenQ Dynamic Black technology dynamically adjusts the projection light output by detecting imagery, ensuring optimal contrast and lifelike images. Laser projectors, equipped with fast dimming, promptly response to brightness changes, delivering 20% higher contrast than other SSI models.

2D Lens Shift

W5800 employs 2D lens shift (±50% vertical and ±21% horizontal) to provide perfectly straight-edged images without loss of resolution, allowing more flexible installation and placement options.

Immersive Silence

The W5800 is equipped with a low-noise multi-channel cooling system, that effectively reduces environmental noise to a quiet range of 27dB to 30dB.

Projection System‎	DLP‎
Native Resolution	4K UHD (3840 x 2160)‎
Brightness (ANSI Lumens)‎	2600 ANSI Lumens‎
Contrast Ratio‎ (FOFO)	2,000,000:1‎
Display Color‎	30 Bits (1,07 billion colors)‎
Aspect Ratio‎	Native 16:9 (6 aspect ratio selectable)‎
Throw Ratio‎	1.52~2.45 (100" @ 3.25 m)‎
Projection Size‎	60" ~ 200" / 300"‎
Zoom Ratio‎	1.6X‎
Projection Offset**‎	0%‎
Resolution Support‎	VGA (640 x 480) to 4K UHD (3840 x 2160)‎
3D Compatibility‎	Frame Sequential: Up to 1280×720 120Hz Frame Packing: Up to 1080p 24Hz Side by Side: Up to 1080i 60Hz Top Bottom: Up to 720p 60Hz
Horizontal Frequency‎	15K-135KHz‎
Vertical Scan Rate‎	23-240Hz‎
HDTV Compatibility‎	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p‎
Weight‎	10.5 kg / 23.1 lbs‎
Dimensions (W x H x D mm)‎	525.2×145.7×392.2
Interface‎	HDMI in (x2) LAN (RJ45) (10/100 Mbps), (x1) 3D Sync out(x1) VESA USB Type A (x2) USB Type B (x1) USB Type B-1(service) RS232 in (DB-9pin) (x1)
Power Consumption‎	Max 450W/ Normal 380W/ ECO 240W
DMD type‎	0.47"‎
Light Source‎	Laser
Light Source Life*‎	a. Normal 20000 hrs, b. ECO 25000 hrs
Noise Level‎	30dBA / 27dBA
Build in Speaker‎	No.
Operating Temperature‎	0~40 degrees (Celsius)‎
Standby Power Consumption‎	0.5W‎
